Specs at a glance Accuracy: +/-1 mm (0.04 in) Process temperature: -40 … +200 °C (-40 … +392 °F) Process pressure / max. overpressure limit: Vacuum...20 bar (290 psi) Max. measurement distance: 50 m (164 ft) Main wetted parts: PVDF, PTFE or PEEK ---------------------------------------- Field of application Endress Hauser's Micropilot FMR60B is part of the new generation of 80 GHz radar sensors. It is used for continuous non-contact level measurement in simple liquid applications with small process connections. Wizards guide users through commissioning, proof tests and verification of the devices and thus guarantee a simple operation. Heartbeat Technology offers verification and monitoring functions to identify anomalies for more safety and increased productivity. • Process connections: Threads and flanges • Temperature: –40 to +200 °C (-40 to 392° F) • Pressure: –1 bis +20 bar (-14.5 to +290 psi) • Maximum measuring range: 50 m (164 ft) • Accuracy: ±1 mm (0.04 in) • W-band: 80 GHz • International explosion protection certificates, overfill prevention WHG, SIL, marine approval, 5- or 10-point factory calibration certificate
